ASTM A453 Gr 660 Stainless Steel Bolt, ASTM A453 660 Class A/B/C/D Bolts, Nuts, Stud Bolts, Washers Supplier in India
Ratna Exports specialize in manufacturing high-quality Stud Bolts, Hex Bolts, Heavy Hex Bolts, Socket Head Cap Screws, Threaded Rods, Nuts, and Washers according to ASTM A453 Grade 600 Class A/B/C & D standards. Our Grade 660 Bolts are available in sizes ranging from 3/8″ to 4″ in imperial measurements and up to M100 in metric sizes. We offer customization upon request for larger bolts based on specific requirements and drawings. We maintain a stock of premium and surplus bar stock in Grade 660 (UNS S66286; Alloy A286) to facilitate quick manufacturing and shorter delivery times. Our ASTM A453 Grade 660 Class A/B/C/D Bolts come with EN 10204 Type 3.1 Material Test Certificates (MTC), ensuring traceability and quality assurance. Additionally, we provide a Rupture Test Facility for sufficient quantity orders. ASTM A453 Grade 660 is a specification designed for studs, bolts, nuts, and other fasteners for high-temperature applications. This grade is classified into four property classes: A, B, C, and D, each with different tensile and stress rupture properties. These fasteners are commonly used in bolting applications for boilers, pressure vessels, pipeline flanges, and valves operating at elevated temperatures. ASTM A453 Grade 660 material is chemically equivalent to ASTM B638 Grade 660 stainless steel alloy, also known as Alloy A286 and UNS S66286. It undergoes heat treatment to achieve the properties specified in the ASTM A453 standard.
Typically, A453-660 Class C bolts are manufactured in sizes ranging from 3/8″ to 4″ in imperial units, while in metric terms, A453 Gr 660 nuts are produced up to size M100. However, if buyers require larger-sized A453 Gr 660 bolts, they can be custom-made upon request. A453 660 Class D specification fasteners are precipitation hardening, austenitic stainless steel components designed for high or elevated temperatures, reaching up to 1300°F or 704°C. At elevated temperatures, A453 Gr 660 Class D fasteners exhibit enhanced properties such as high tensile strength and excellent creep strength. Additionally, they offer good corrosion resistance for various applications. The ASTM A453 Gr 660 Stainless Steel Bolt Specification covers high-temperature bolting with expansion coefficients comparable to austenitic stainless steel. These fasteners are primarily intended for special engineering applications, including those in industries involved in oil production and infrastructure projects.
A453 Gr 660 Cl 1 to 5 Stud Bolt, ASTM A453 Grade 660 Fastener, ASTM A453 Gr 660 Stainless Steel Bolt In Mumbai, India, ASTM A453 Gr 660 Class A/B/C/D Stud Bolts At Factory Price In India
As a result, ASTM A453 Grade 660 B specification studs and bolts are available in various sizes and coatings to meet diverse requirements. We are a reputable supplier of ASTM A453 Grade 660 stud bolts based in India, offering high-quality products tailored to meet specific needs. For more detailed information on chemical composition, mechanical properties, tensile class, heat treatment definitions, available products, bar stock sizes, applicable dimension standards, and other relevant details, please get in touch with us.
Contact Ratna Exports today for a best offer & competitive quotation Of ASTM A453 Grade 660 Class A/B/C/D Fasteners
ASTM A453 Grade 660 Bolts Specification Chart
Dimensions | ASME B18.2.1, B18.3 |
Standard | ASTM A453 gr 660/ ASME SB453 gr 660 |
Melt Origin | Korea, Japan, South America, East Europe |
Mandatory Requirements | Free from Radioactive Contamination And Mercury |
Certification | Dual Certified As per ASTM and ASME Standards |
Additional Requirements | NACE MR0103 / ISO 15156 Compliance / MR0175 |
Threads Configuration | B1.1 2A or 3A Inch Unified Threads B1.13M 6h Metric Coarse Threads |
types of ASTM A453 Gr 660 Bolt
ASTM A453 Gr 660 Class A Stud Bolts
ASTM A453 Gr 660 Class A Socket Head Cap Screws
ASTM A453 Gr 660 Panel Screws
304 Stainless Steel Stud Bolts
ASTM A453 Gr 660 Equivalent Grade
AISI | UNS | BS | Wr No. | En Name | DIN EN | JIS | AMS | ASTM | other names | Additional Requirements | |
660 | S 66286 | HR 51 | 1.4944 | X6NiCrTiMoV26-15 | 10269 | SUS 660 | 5726 | ASTM A453 GRADE 660A | Incoloy a286 | NACE MR-0175 |
Chemical Composition Of A453 Gr 660 Bolt
ELEMENT | Grade 660 | Grade 651 | Grade 662 | Grade 665 | Grade 668 |
% | % | % | % | % | |
Carbon | 0.08 max | 0.28-0.35 | 0.08 max | 0.08 max | 0.08 max |
Manganese | 2.00 max | 0.75-1.5 | 0.40-1.00 | 1.25-2.00 | 2.00 max |
Phosphorus, max | 0.040 max | 0.040 max | 0.040 max | 0.040 max | 0.040 max |
Sulfur, max | 0.030 max | 0.030 max | 0.030 max | 0.030 max | 0.030 max |
Silicon | 1.00 max | 0.30-0.80 | 0.40-1.00 | 0.1-0.80 | 1.00 max |
Nickel | 24.0-27.0 | 8.0-11.0 | 24.0-28.0 | 24.0-28.0 | 17.5-21.5 |
Chromium | 13.5-16.0 | 18.0-21.0 | 12.0-15.0 | 12.0-15.0 | 13.5-16.0 |
Molybdenum | 1.00-1.50 | 1.00-1.75 | 2.0-3.50 | 1.25-2.25 | 1.50 max |
Tungsten | … | 1.00-1.75 | … | … | … |
Titanium | 1.9-2.35 | 0.1-0.35 | 1.80-2.10 | 2.70-3.30 | 2.20-2.80 |
Columbium * | … | 0.25-0.6 | … | … | … |
Aluminum | 0.35 max | 0.35 max | 0.25 max | 0.50 max | |
Vanadium | 0.10-0.50 | … | … | 0.50 max | |
Boron | 0.001-0.010 | 0.001-0.010 | 0.01-0.07 | 0.001-0.010 | |
Copper | 0.50 max | 0.50 max | 0.25 max | … |
SA453 Gr 660 Bolt Mechanical Properties
Size | Class | Tensile, Mpa | Yield, Mpa | Elong. %, min | RA %, min |
Grade 660 | A, B, & C | 895 min | 585 min | 15 | 18 |
D | 895 min | 725 min | 15 | 18 | |
Grade 651 | A | 690 min | 485 min | 18 | 35 |
415 min | |||||
B | 655 min | 415 min | 18 | 35 | |
345 min | |||||
Grade 662 | A | 895 min | 585 min | 15 | 18 |
B | 860 min | 550 min | 15 | 18 | |
Grade 665 | A | 1170 min | 830 min | 12 | 15 |
B | 1070 min | 830 min | 12 | 15 | |
Grade 665 | A & B | 895 min | 858 min | 15 | 18 |
ASTM A453 Gr 660 Bolts Dimensions
NOMINAL SIZE (D) | BODY DIAMETER | HEAD THICKNESS ASTM A193 | ACRO ASTM A193, THE FLATS | ACROASTM A193 CORNERS | ||||
D (MAX) | D (MIN) | H (MAX) | H (MIN) | F (MAX) | F (MIN) | C (MAX) | C (MIN) | |
m10 | 10.00 | 9.78 | 6.63 | 6.17 | 17.00 | 15.73 | 18.48 | 17.77 |
m12 | 12.00 | 11.73 | 7.76 | 4.24 | 19.00 | 17.73 | 20.78 | 20.03 |
m14 | 14.00 | 13.73 | 9.09 | 8.51 | 22.00 | 20.67 | 24.25 | 23.35 |
m16 | 16.00 | 15.73 | 10.32 | 9.68 | 24.00 | 23.67 | 27.71 | 26.75 |
m20 | 20.00 | 19.67 | 12.88 | 12.12 | 30.00 | 29.16 | 34.64 | 32.95 |
m24 | 24.00 | 23.67 | 15.44 | 14.56 | 36.00 | 35.00 | 41.57 | 39.55 |
m30 | 30.00 | 29.67 | 19.48 | 17.92 | 46.00 | 45.00 | 53.12 | 50.85 |
m36 | 36.00 | 35.61 | 23.38 | 21.63 | 55.00 | 53.80 | 63.51 | 60.79 |
m42 | 42.00 | 41.38 | 26.97 | 25.03 | 65.00 | 62.90 | 75.06 | 71.71 |
m48 | 48.00 | 47.38 | 31.07 | 28.93 | 75.00 | 72.60 | 86.60 | 82.76 |
m56 | 56.00 | 55.26 | 36.2 | 33.80 | 85.00 | 82.20 | 98.15 | 93.71 |
m64 | 64.00 | 63.26 | 41.32 | 38.68 | 95.00 | 91.80 | 109.70 | 104.65 |
m72 | 72.00 | 71.26 | 46.45 | 43.55 | 105.00 | 101.40 | 121.24 | 115.60 |
m80 | 80.00 | 79.26 | 51.58 | 48.42 | 115.00 | 111.00 | 132.72 | 126.54 |
m90 | 90.00 | 89.13 | 57.74 | 54.26 | 130.00 | 125.50 | 150.11 | 143.07 |
m100 | 90.00 | 99.13 | 63.9 | 60.10 | 145.00 | 140.00 | 167.43 | 159.60 |
Looking to buy ASTM A453 Grade 660 Class A/B/C/D Fasteners From a manufacturer in India?
Other Types Of ASTM A453 Gr 660 Bolts
ASTM A 453 GR 660 Heavy Hex Bolts | Grade 660 Shoulder Bolt |
ASTM A453 GR 660 Class A Anchor Bolt | ASTM A453 660 Stud Bolts |
ASTM A 453 Eye Bolt Supplier | ASTM A 453 GR 660 Class B Stud Bolt |
Grade 660 Step Bolt | Stainless Steel GR 660 Studs Manufacturer |
ISO Approved ASTM A453 U Bolts | SS Grade 660 Plow Bolt Distributor |
Class D Nuts Exporter | GR 660 Grub Screw |
Stainless Steel GR 660 Threaded Rod | ASTM A453 J Bolt |
ASTM A453 stud bolts Supplier | A453 Grade 660 Hex Nut |
ASTM A 453 GR 660 Class B Lag Bolt Exporter | ASTM A453 stud bolts Supplier |
Stainless Steel Gr 660 Draw Bolt Supplier | Grade 660 Hanger Bolt |
ASTM A 453 Tie Rod | ASTM A 453 GR 660 Class D Studs Manufacturer |
GR 660 Stainless Steel Stud bolts | ASTM A453 660 Class D Stud Bolts |
Please note this is an approx ASTM A453 Grade 660 Class A/B/C/D Fasteners price in India. For final ASTM A453 Grade 660 Class A/B/C/D Fasteners price list please mail us.
ASTM A453 Gr 660 Studs Bolt Sizes
Diameter | Diameter in mm | Diameter in inch | Nut Sizes |
M12 | 12 | 0.4724 | 19 |
M10 | 10 | 0.3937 | 17 |
M14 | 14 | 0.5512 | 22 |
M18 | 18 | 0.7087 | 27 |
M16 | 16 | 0.6299 | 24 |
M20 | 20 | 0.7874 | 30 |
M24 | 24 | 0.9449 | 36 |
M22 | 22 | 0.8661 | 32 |
M27 | 27 | 1.063 | 41 |
M33 | 33 | 1.2992 | 50 |
M30 | 30 | 1.1811 | 46 |
M36 | 36 | 1.4173 | 55 |
M42 | 42 | 1.6535 | 65 |
M39 | 39 | 1.5354 | 60 |
M45 | 45 | 1.7717 | 70 |
M52 | 52 | 2.0472 | 80 |
M48 | 48 | 1.8898 | 75 |
M56 | 56 | 2.2047 | 85 |
M64 | 64 | 2.5197 | 95 |
M60 | 60 | 2.3622 | 90 |
M68 | 68 | 2.6772 | 100 |
M76 | 76 | 2.9921 | 110 |
M72 | 72 | 2.8346 | 105 |
M80 | 80 | 3.1496 | 115 |
M90 | 90 | 3.5433 | 130 |
M85 | 85 | 3.3464 | 120 |
M100 | 100 | 3.937 | 145 |
M160 | 160 | 6.2992 | 230 |
M125 | 125 | 4.9212 | 180 |
M110 | 110 | 4.3307 | 155 |
M140 | 140 | 5.5118 | 200 |
Astm A453 Grade 660 Nut Weight Chart
Sizes | Weight per Metre | Size (UNC) | Weight per Meter |
M2 | 0.0187 | ||
M2.5 | 0.030 | ||
M3 | 0.044 | ||
M3.5 | 0.060 | ||
M4 | 0.078 | ||
M5 | 0.124 | ||
M6 | 0.177 | ¼ | 0.194 |
M8 | 0.319 | 5/16 | 0.323 |
M10 | 0.500 | 3/8 | 0.469 |
7/16 | 0.650 | ||
M12 | 0.725 | ½ | 0.896 |
M14 | 0.970 | 9/16 | 1.096 |
M16 | 1.330 | 5/8 | 1.342 |
M18 | 1.650 | ||
M20 | 2.080 | ¾ | 2.021 |
M22 | 2.540 | 7/8 | 2.756 |
M24 | 3.000 | 1 | 3.638 |
M27 | 3.850 | 1 1/8 | 4.545 |
M30 | 4.750 | One ¼ | 5.718 |
M33 | 5.900 | 1 3/8 | 6.842 |
M36 | 6.900 | 1 ½ | 8.281 |
M39 | 8.200 | 1 5/8 | 9.726 |
M42 | 9.400 | One ¾ | 11.231 |
M45 | 11.000 | 1 7/8 | 13.038 |
M48 | 12.400 | 2 | 14.741 |
Application of Astm A453 Gr 660 Cl 1to 5
A286 Grade 660 Bolts used in Pharmaceutical Equipment
SUS 660 Bolts used in Sea Water Equipment
Incoloy A286 Hex Nuts uses in Heat Exchangers
A453 Grade 660 Heavy Hex Bolts used in Gas Processing
SA453 Grade 660 Stud Bolts used in Specialty Chemicals
ASTM A453 Werkstoff No. 1.4944 Bolts used in Spiral Welded tube for burner pipes and flues
ASTM A453 Grade 660 Bolts used in Aircraft Exhaust Manifolds
ASTM A453 Grade 660 Fasteners used in Pharmaceuticals
Applications Industry ASTM A453 Grade 660 Class A/B/C/D Fasteners
- Pharmaceutical Industry
- Oil Refineries
- Textile Industries
- Nuclear Plants
- Chemical Industries
- Power Plant
- Petrochemicals Industry
- Sugar Industry
- Engineering Industry
- Chemical Industry
- Food Industry
- Marine Industry
