BS 6323 Carbon Steel, Carbon Steel BS 6323-5 Pipes and Tubes, BS 6323-5 Grade HFS 5 Carbon Steel Seamless Tubes Supplier in India
BS 6323 Carbon Steel ERW Air Pre Heater Pipes are steel pipes designed for air pre-heaters. Air pre-heaters are devices that increase air temperature before they are used in combustion processes. This can improve the efficiency of the combustion process and reduce emissions.
BS 6323 Grade CFS 4 Carbon Steel Seamless Tubes, often referred to as mild steel pipes and tubes, offer an economical solution for various applications. With a maximum carbon content of 0.25% and a manganese concentration of 1.20%, these tubes are easy to shape and form. Manufactured to BS specifications, they are commonly recognized as CS (carbon steel) pipes or MS (mild steel) pipes in the market.
Low carbon steel pipes, such as BS 6323 Grade CFS 4 Tubes, are distinguishable from high carbon steel pipes due to their softer nature. However, their surface hardness can be enhanced through carburizing processes.
The surface polish of CEW Oil Draw Tubes has undergone significant improvement, enhancing their mechanical properties compared to Cold Drawn Seamless Tubes. This advancement results in products with superior yield and tensile strength. Cold-formed steel exhibits higher mechanical strength, making it an ideal choice for automotive applications such as scooters and motorcycles. These tubes cater to the requirements of both CEW (Cold Electric Welded) and ERW (Electric Resistance Welded) tubes in the automotive sector. Moreover, their cost-effectiveness is a major advantage.
BS 6323 Part 5, BS 6323 ERW, BS 6323 Carbon Steel Erw Air Pre Heater Tubes Exporter in India
BS 6323 Grade CFS 4 Carbon Steel Seamless Tubes come with Mill Test Certification according to EN 10204 Type 3.1/3.2 standards. The designation “3.2” signifies in-stage inspection conducted by independent agencies like TUV, DNV, BVQS, LLOYDS & EIL.
Additionally, adherence to IBR (Indian Boiler Regulations), NACE MR 0175, NACE MR 0103, HIC (Hydrogen Induced Cracking), IGC (Intergranular Corrosion), and IMPACT (Impact Testing) is ensured, with supplementary testing requirements fulfilled by government-approved NABL laboratories. BS 6323 Grade CFS 4 Tubes are supplied in varnished condition to prevent rust formation.
BS 6323: This refers to the British Standard that specifies the requirements for these pipes. This standard covers the pipes’ dimensions, tolerances, material properties, and other technical requirements.
Contact Ratna Exports today for a best offer & competitive quotation Of BS 6323 Part V ERW Pipes
BS 6323 Part V ERW Pipes Specification Chart
Dimensions | ASME B18.2.1, B18.3 |
Standard | ASTM A194 2H/ ASME SB194 2H |
Melt Origin | Korea, Japan, South America, East Europe |
Mandatory Requirements | Free from Radioactive Contamination and Mercury |
Certification | Dual Certified As per ASTM and ASME Standards |
Additional Requirements | NACE MR0103 / ISO 15156 Compliance / MR0175 |
Threads Configuration | B1.1 2A or 3A Inch Unified Threads B1.13M 6h Metric Coarse Threads |
Suppliers and Distributors Located in | Melbourne, Ludhiana, London, Bangalore, Port of Spain, Courbevoie, Coimbatore, Bogota, Hyderabad, Kanpur, Karachi, Baroda, Caracas, Bengaluru, Manama, Kolkata, Montreal, Gujarat, Riyadh, Santiago, Perth, Rajkot, Ankara, Nagpur, Chennai, Indore, Istanbul, Ahvaz, Jamshedpur, Janeiro, Muscat, Noida, Ranchi, Sydney, Lagos, Ahmedabad, Gimhae si, India, New Delhi, Pimpri Chinchwad, Mumbai, Abu Dhabi, Ludhiana, Gurgaon, Tehran, Thiruvananthapuram, Dammam, Vadodara, Tau, Surat, Kuwait, Ernakulam, Mexico, Calgary, Khobar, Howrah |
Types of BS 6323 Part V ERW Pipes
Carbon Steel ERW Pipes
SS ERW Pipes
Alloy Steel ERW Pipes
Copper ERW Pipes
Nickel Alloy ERW Pipes
Erw Square Pipes
ERW Hex Pipes
Rectangular ERW Pipes
Properties of BS 6323 Carbon Steel ERW Air Pre Heater Tubes:
- Made from carbon steel
- Welded using the ERW process
- Conforms to the BS 6323 standard
- Available in a variety of sizes and thicknesses
- It can be used in a wide range of temperatures and pressures.
BS 6323 Part V ERW Pipes Equivalent Grade
Standard | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
DIN 23912 grade | – | – | – | – | – | – | EN 1.0408 Grade St 45 |
Looking to buy from BS 6323 Part V ERW Pipes manufacturer in India?
BS 6323 Part V ERW Pipes Chemical Properties
Chemical Properties | ||||||||||
Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others | |
CFS6 | 0.30-0.40 | max 0.35 | 0.50-0.90 | 0.050 | 0.050 | – | – | – | – |
Please note this is an approx BS 6323 Part V ERW Pipes price in India. For final
Carbon Steel BS 6323-5 Pipes price list please mail us.
BS 6323 Part V ERW Pipes Mechanical Properties
Mechanical Properties | |||||
Yield Strength | Tensile Strength | Elongation A5 min | |||
MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
CFS6 | 350 | – | – | 540 |
BS 6323 Part V ERW Pipes Materials
Carbon Steel | Low-Temperature Carbon Steel | Low-Temperature Alloy Steel |
Alloy Steel | High-Temperature Carbon Steel | High-Temperature Alloy Steel |
BS 6323 Part V ERW Pipes Dimensional Tolerance
The outer diameter and wall Thickness | |||
Execution | Size Range | OD Tolerance | Wall tolerance |
Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wall thickness + 0.1 mm |
Hot-rolled peeled tube | All sizes < 12 small – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness 0.2 mm) |
Cold Worked tube cold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Straightness
The maximum deviation from the straight line is 1 mm on a gauge length of 1000 mm.
Ovality
The maximum out-of-roundness is 65% of the total outer diameter tolerance.
Standard Length Tolerance
Component length (mm) | OD 30-100 mm | OD 100-254 mm |
10-100 | + 1.0/- 0 | + 2.0/- 0 |
100-600 | + 2.0/- 0 | + 3.0/- 0 |
600-1200 | + 3.0/- 0 | + 4.0/- 0 |
1200-5000 | + 5.0/- 0 | + 6.0/- 0 |
BS 6323 Part V ERW Pipes Delivery Executions and Protection
Tube Ends | Protection |
We Supply all tubes with clean, square-cut ends. Deburring and chamfering, we carry out on request on request. | • Black and Bare • External Varnished with Black or Clear Lacquer |
Tube surface | Mill test certificate. |
We supply Tubes without anti-corrosive treatment, but anti-corrosive treatment is available, and we carry it out on request. | • MTC is issued by EN 10204. |
BS 6323 Part V ERW Pipes Types
Pipes | Tubes | Hollow Sections |
Seamless Pipes | Seamless Tubes | Pipes |
• Cold Drawn Seamless Pipes | • Cold Drawn Seamless Tubes | • Boom Pipe • Square Pipes |
• Hot Drawn Seamless Pipes | • Hot Drawn Seamless Tubes | • Culvert Pipes • Round Pipes • Honed Pipes |
Welded Pipes | Welded Tubes | Tubes |
• Electric Resistance Welded(ERW) Pipes | • Electric Resistance Welded(ERW) Tubes | |
• Continuous Welded(CW) Pipes | • Continuous Welded(CW) Tubes | |
• Submerged Arc Welded(SAW) Pipes | • Submerged Arc Welded(SAW) Tubes | • Boom Tubes |
• Spiral Welded Pipes | • Spiral Welded Tubes | • Square Tubes |
• High Frequency Induction(HFI) | • High Frequency Induction(HFI) | • Round Tubes |
• Longitudinally Submerged Arc Welded(LSAW) Pipes | • Longitudinally Submerged Arc Welded(LSAW) Tubes | • Honed Tubes |
BS 6323 Part V ERW Pipes Manufacturing Types
- Seamless cold-drawn tubes
- Welded cold-drawn tubes
- Welded Cold Sized Tubes
- Seamless cold-drawn tubes for hydraulic and pneumatic power system
- Welded Cold Sized rectangular and square tubes
- Welded cold-drawn tubes for pneumatic and hydraulic power system
BS 6323 Part V ERW Pipes Diameter Tolerance BS 6323 Part V ERW Pipes Diameter Tolerance
T/D-ratio | Tolerance limits |
≥0.05 | 1 |
0.05>T/D≥0.025 | 1.5 |
<0.025 | 2 |
BS 6323 Part V ERW Pipes Key Features
- Weld quality that is second to none
- Having in-house steel-making, hot rolling, and cold rolling facilities allows us to provide a wide range of steel grades to our customers.
- We are capable of supplying high-strength tubes that are also highly malleable.
- A capability to manufacture ERW/CEW tubes with tight tolerances on the outside diameter and the thickness of the tubes
- Bright normalized surface requirements on request
- Cladding Plate Manufacturers In India, Steel Cladding Plate Manufacturers, Stainless Steel Cladding Plate Manufacturers
- We integrated a cold drawing line with a high-speed cold draw bench, multi-roll straightener, NDT, multi-head tube cutting, deburring, and packaging system.
- This cold-drawn line has a ten-roll CNC straightener to ensure the tubes are straight to the last inch.
- Furnace for bright annealing – Fully Automatic roller hearth furnace with provision for normalizing, annealing, and tempering operations simultaneously.
- Customized Tube Cutting Line with Telescopic Front Fork to suit the length specifications of the customer.
- PLC-based predefined recipe system controls process parameters such as dipping time, rinsing time, drainage angle, and holding time during the surface treatment process.
DBS 6323 Part V ERW Pipes Sizes
Size (mm) | Wall Thickness (mm) | |||||
1.0 | 1.2 | 1.5 | 2.0 | 2.5 | 3.0 | |
12.7 x 12.7 | o | o | o | o | ||
15 x 15 | o | o | o | o | ||
15.8 x 15.8 | o | o | o | o | ||
19.05 x 19.05 | o | o | o | o | ||
20 x 20 | o | o | o | o | o | |
22 x 22 | o | o | o | o | ||
22.2 x 22.2 | o | o | o | o | ||
25 x 25 | o | o | o | o | o | o |
25.4 x 25.4 | o | o | o | o | o | o |
30 x 30 | o | o | o | o | o | |
31.7 x 31.7 | o | o | o | o | o | |
35 x 35 | o | o | o | o | o | |
38.1 x 38.1 | o | o | o | o | o | |
40 x 40 | o | o | o | o | o | |
45 x 45 | o | o | o | o | ||
50 x 50 | o | o | o | o | ||
50.8 x 50.8 | o | o | o | o |
Applications of BS 6323 Carbon Steel ERW Air Pre Heater Tubes:
- Air pre-heaters
- Power plants
- Refineries
- Chemical plants
- Other industrial applications
