It is our pleasure to offer the SS Physical Vapor Deposition Sheets at Ratna Exports to all of our esteemed customers around the world as well as locally in high quality. PVD is the process by which material is vaporized from condensation on various surfaces in a vacuum environment. In the field of architecture and building construction, automotive trim, electronic components, etc., physical vapor deposition is a vacuum coating process that is atmospheric friendly that produces durable, brilliant decorative finishes.
As a result, a vast range of colors can be achieved combining the advantages of the decorative finishes with excellent wear and corrosion resistance. This offers you long-lasting finishes that don’t easily corrode, chip, fade or tarnish out of your imagination or creations.
The PVD sheets are easily available to the buyers in a variety of colors, including gold, white gold, red wine, bronze, rose gold, green, black, nickel silver, Champaign, copper, and many more. They are used in applications such as exterior facades, interiors, lift cladding, signage and many more.
In order to meet the specific requirements of our clients, it is made available to them in a variety of standard specifications, varying in wall thickness, grade, finishes, etc. In addition to this, it is also available to them in custom specifications, built according to the exact specifications they have requested.
In addition to manufacturing, stocking, supplying, and distributing PVD Sheets, Ratna Exports is also known as Titanium/Zirconium plating. PVD coating stands for Physical Vapor Deposition of Titanium or Zirconium. Using this method, a colored film can be applied to a stainless steel substrate in a vacuum chamber. The colored film is able to last for a very long time without fading, regardless of the interior or exterior conditions. As a result of its high wear and hardness resistance, discoloration, tarnishing, corrosion and UV radiation resistance properties, Top Honest PVD coating stainless steel is a unique material for decorating applications. In harsh environments, such as in the sun, humidity, salt, and the city environment, our PVD coated stainless steel sheets will not tarnish, oxidize, or discolor, and they are available in a wide range of colors, patterns and finishes.
These sheets are available in a variety of colors of PVD coating, such as Gold, Brass, Rose Gold, Silver, Smoke Grey, Copper, Bronze, Blue, Black, Purple, Brown, Wine Red, etc. The PVD coloured stainless steel sheet is mainly used as a cladding material for building applications such as column covers, elevator doors, escalators, moving walks, decorative and ornamental cladding, hotel entrances, architectural trims, telephone booths, etc. In the home fixture industry, however, these sheets are used for a variety of purposes including kitchen appliances, cabinet doors, mail boxes, etc.
Application
Construction
Item Code
BWPJUG
Color
PVD colour
Grade
304, 316, 316L
Width
1220, 1500, 2000 mm
Finish
Brush, Mirror, Hairline, Vibration, 2B, BA, #1, Marble Design, Perforation, Embossing
Length
2440, 3050, 3000, 6000 mm
Pattern
Etch Pattern
Material
Stainless Steel
Thickness
0.4 – 25 mm
Element | SS 304 | SS 304L | SS 316 | SS 316L |
C | 0.08 max | 0.035 max | 0.08 max | 0.035 max |
Mn | 2 max | 2.0 max | 2.0 max | 2.0 max |
Si | 0.75 max | 1.0 max | 1.0 max | 1.0 max |
P | 0.045 max | 0.045 max | 0.045 max | 0.045 max |
S | 0.030 max | 0.03 max | 0.030 max | 0.03 max |
Cr | 18 – 20 | 18 – 20 | 16.00 – 18.00 | 16.00 – 18.00 |
Mo | – | – | 2.00 – 3.00 | 2.00 – 3.00 |
Ni | 8 – 11 | 8 – 13 | 11.00 – 14.00 | 10.00 – 14.00 |
Fe | – | – | 67.845 min | 68.89 min |
Element | SS 304 / 304L | SS 316/316L |
Density | 8.0 g/cm3 | 8.0 g/cm3 |
Melting Point | 1400 °C (2550 °F) | 1400 °C (2550 °F) |
Tensile Strength | Psi – 75000 , MPa – 515 | Psi – 75000 , MPa – 515 |
Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 | Psi – 30000 , MPa – 205 |
Elongation | 35 % | 35 % |
Standard | SS 304 | SS 304L | SS 316 | SS 316L |
WERKSTOFF NR. | 1.4301 | 1.4306 / 1.4307 | 1.4401 / 1.4436 | 1.4404 / 1.4435 |
UNS | S30400 | S30403 | S31600 | S31603 |
JIS | SUS 304 | SUS 304L | SUS 316 | SUS 316L |
BS | 304S31 | 3304S11 | 316S31 / 316S33 | 316S11 / 316S13 |
GOST | 08Х18Н10 | 03Х18Н11 | – | 03Ch17N14M3 / 03Ch17N14M2 |
AFNOR | Z7CN18‐09 | Z3CN18‐10 | Z7CND17‐11‐02 | Z3CND17‐11‐02 / Z3CND18‐14‐03 |
EN | X5CrNi18-10 | X2CrNi18-9 / X2CrNi19-11 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
In the aerospace electronics industry, titanium, zirconium, aluminum, stainless steel, and copper are the most common PVD coating materials. For aerospace electronics, gold is often requested, however. In addition to nylon, plastics, glass, ceramics and metals, such as stainless steel and aluminum, these coatings can also be applied to a wide variety of substrates.
Please note this is an approx PVD Sheets price in India. For final PVD Coated Sheet price list please mail us.
